Details

  • Lightweight aluminum alloy frame and fork deliver a speedy and agile ride
  • Integrated fenders keep you dry when the road is not
  • Integrated cargo rack is pannier-ready
  • Shimano triple crank and Deore 9-speed rear derailleur provide 27 gear combinations
  • Tektro ACC hydraulic disc brakes provide worry-free stopping power
  • Integrated kickstand
  • REI is proud to be the exclusive U.S. retailer of GHOST brand bikes
  • Specs are subject to change

Imported.

All bicycles sold at REI include a free warranty tune-up. New bikes go through a normal break-in period, after which readjustment is important for longevity and performance. Bring your new bike in to your local REI for its free tune-up within 20 hours of use or 6 months from purchase, whichever comes first. Contact your nearest REI bike shop to schedule this important service.

CHOOSE REI STORE PICK UP, GET FREE SHIPPING & ASSEMBLY

When you purchase your GHOST-brand bike on REI.com, have it shipped to any REI store where it will be ready for pick up fully assembled (and you'll avoid the home-delivery oversize shipping charge)!


View all GHOST Hybrid Bikes

REI membership

Specs

Best Use Urban Cycling
Frame Aluminum alloy
Bike Suspension No Suspension
Fork Alloy rigid
Crankset Shimano FC 371 48-36-26
Shifters Shimano Acera SL
Front Derailleur Shimano 390
Rear Derailleur Shimano Deore 9-Speed
Rear Cogs Shimano 11-32
Number of Gears 27
Brake Type Hydraulic Disc Brake
Brakes Tektro ACC hydraulic disc 160mm
Brake Levers Tektro ACC hydraulic disc
Rims ALEX TD19 700C
Front Hub GHOST Disc QR
Rear Hub GHOST Disc QR
Wheel Size 700c
Tires Schwalbe Kojak 700x35
Tire Width 35 millimeters
Handlebar Shape Riser Bar
Handlebar GHOST Low Rizer
Stem GHOST AS GH2 31.8mm
Seat Post GHOST light DC1 31.6mm
Saddle GHOST 2059 HRN
Pedals N/A
Chain Shimano 9-Speed
Weight 29 lbs. 5 oz.
Gender Unisex

Size chart

Sizing notes

All measurements are stated in millimeters or degrees unless otherwise indicated.

Graphic of a bike and its measurements

How we measure bikes

Understanding bike geometry helps you get a perfect fit.

1. Reach

2. Stack

3. Effective Top Tube

4. Seat Tube Center to Top

5. Standover Height

6. Head Tube Length

7. Head Tube Angle

8. Seat Tube Angle

9. Bottom Bracket Height

10. Wheelbase

11. Chainstay Length

12. Fork Offset

  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 166ms
  • REVIEWS, PRODUCT
  • bvseo-msg: The resource to the URL or file is currently unavailable.;

is there clearance for a wider tire? maybe a 700c x 40 mm?

Asked by: allan
Due to the integrated fenders on this bike, the maximum recommended tire width is 35mm.
Answered by: REIservice
Date published: 2017-06-19

How do i measure my size to S M L XL?

Asked by: dawgbird
Here are the standover heights: S - 735mm/28.9" M - 770mm/30.3" L - 815mm/32.1" XL - 855mm/33.7"
Answered by: REIservice
Date published: 2016-10-14

Do the Thule Shield Panniers fit on the integrated rack on this bike? If not, what pannier are recommended

Asked by: Matthew
The Thule Shield Panniers will fit on the cargo rack that comes with this bike.
Answered by: REIservice
Date published: 2017-04-10

What's the maximum weight (rider + accessories) supported by this bike's M and L sizes?

Asked by: Areh
​The Square bike line has a 265 lb. weight limit for rider and gear.
Answered by: REIservice
Date published: 2017-06-23

Do you have any info on TD19 rims? I'm trying to find some info on the Alex TD19 rims and not having much luck. Tried to contact Alex through their web site (email) and the emails bounce back at me as bad email addresses.

Asked by: HammelBrau
The Alex TD19 is a standard rim that comes on many of the GHOST bike models. It is a double wall, 32-hole rim. The front rim weighs 1029 grams (without the rotor) and 1423 grams for the rear.
Answered by: REIservice
Date published: 2017-05-18

Could you please list specs for each size of this model? Thanks.

Asked by: snoboardz
Here are the standover heights: S 735mm/28.9" M 770mm/30.3" L 815mm/32.1" XL 855mm/33.7"
Answered by: REIservice
Date published: 2017-06-21

can you provide size specs, please

Asked by: Sam61
Unfortunately, a geometry chart is not available. We encourage you to visit GHOST Bikes' site to view geometry for the Square Urban series bikes.
Answered by: REIservice
Date published: 2016-10-17

So , what's the spec on the "Sizes" ???

Asked by: SkyTraveler
Here are the standover heights: S 735mm/28.9" M 770mm/30.3" L 815mm/32.1" XL 855mm/33.7"
Answered by: REIservice
Date published: 2016-10-15
