Size chart
| XS | S | M | |
|---|---|---|---|
| Height Range | 4'9"-5'3" | 5'1"-5'6" | 5'5"-5'11" |
| Reach | 371 | 401 | 428 |
| Stack | 586 | 586 | 596 |
| Effective Top Tube | 530 | 560 | 590 |
| Seat Tube Center-Top | 380 | 420 | 460 |
| Standover Height | 695 | 709 | 740 |
| Head Tube Length | 110 | 110 | 120 |
| Head Tube Angle (degrees) | 69 | 69 | 69 |
| Seat Tube Angle (degrees) | 75 | 75 | 75 |
| Bottom Bracket Height | -14 | -14 | -14 |
| Wheelbase | 1062 | 1092 | 1123 |
| Chainstay | 430 | 430 | 430 |
Sizing notes
All measurements are stated in millimeters or degrees unless otherwise indicated.
