Yuba Kombi Compact Cargo Bike

$1,200.00
Color: Matte Yellow
Size: One Size
Quantity
Choose a shipping method

Members get an estimated $120.00 back on this item as a part of your annual .

Members get an estimated $120.00 back on this item.
To buy,  sign in as an REI Co-op Member or join now.

Combining family fun with urban utility, the Yuba Kombi compact cargo bike is your affordable, portable and storable gateway to 2-wheeled freedom, shared adventures and new discoveries.

  • Features

    • For the urban dweller, a shorter wheelbase fits on a bus rack and offers upright storage solutions for the apartment
    • Fits riders 5 ft. to 6 ft. 6 in.
    • Adjustable cockpit and seat post
    • Comfortably carries 2–3 kids
    • Compatible with many Yuba add-ons (not included) and Yepp Nexxt child seat (not included)
    • Included Stand Together double kickstand, front and rear LED battery-powered lights, front fender with rear wheelskirt and bell make riding around the city a breeze
    • Included Deflopilator keeps your front wheel in check when using your dual kickstands by attaching to your down tube
    • Covered by manufacturer's 2-year limited warranty
    • Specs and images are subject to change

    Imported.

    This bike comes with Coast to Coast Support, which includes:
    • 1 year of free adjustments (see more below)
    • In-store bike assembly
    • Pickup in store or curbside
    • Bike experts available at 170+ bike shops
    REI Co-op Members get more:
    • Free flat tire repairs (labor only; parts not included)
    • 20% off shop services
    More about our free adjustments:
    New bikes go through a normal break-in period, after which they should be readjusted. All bicycles sold at REI include free adjustments for one year after purchase date—as many times as you need. Included: derailleur and brake adjustments, lateral wheel truing, hub and headset bearing adjustments, tire inflation and chain lubrication. Not included: replacement or installation of new components or accessories, any other services. Call your local REI Co-op Bike Shop for more information.

    View the Yuba Kombi Product LineView all Yuba Cargo Bikes
  • Technical Specs

    Best Use

    Urban Cycling

    Frame

    Kombi 23 in. steel with disc tabs

    Step-Through

    No

    Bike Suspension

    No Suspension

    Fork

    Cr-Mo 1-1/8 in. threadless with disc tabs

    Crankset

    170mm 6061 Forged Alloy 42t

    Shifters

    Shimano Altus SL-M2010 9-Speed Trigger

    Rear Derailleur

    Shimano RD-M2000

    Rear Cogs

    Sunrace 11-40T 9-Speed

    Number of Gears

    9 gear(s)

    Brake Type

    Mechanical Disc Brake

    Brakes

    Tektro MD-300 mechanical disc

    Brake Levers

    Tektro CL520-RS

    Rims

    Alloy double-wall 36h

    Front Hub

    Alloy Disc 36h

    Rear Hub

    Alloy Disc 36h

    Wheel Size

    24 inches

    Tires

    Kenda 24 x 2.4 in.

    Tire Width

    2.4 inches

    Handlebar Shape

    Moustache Bar

    Handlebar

    31.8mm City handlebars

    Stem

    1-1/8 in. adjustable stem

    Seat Post

    30.9mm aluminum 500mm

    Saddle

    Velo Comfort saddle

    Pedals

    Black nylon flat

    Headset

    Semi-cartridge, 1-1/8 in. threadless

    Chain

    KMC Z9

    Weight

    50 pounds

    Bike Weight

    Bike weight is based on median size, as sold, or the average of two median sizes.

    Gender

    Unisex

  • Size Chart

    One Size
    Height Range5'0''- 6'6"
    Effective Top Tube620
    Seat Tube Center-Top420
    Head Tube Length175
    Head Tube Angle (degrees)71
    Seat Tube Angle (degrees)71
    Wheelbase1240
    Chainstay568
    Fork Offset55

    Sizing Notes

    Measurements are stated in millimeters unless otherwise indicated.

    How we measure bikes

    1. Standover Height Standover Height is a measurement from the ground to the top of the top tube, measured at the midpoint of the top tube.
    2. Reach Reach is the horizontal distance from the center of the cranks to the center of the head tube, measured at head tube level.
    3. Stack Stack is the vertical distance from the center of the cranks to the center of the head tube, measured to the top of the head tube.
    4. Effective Top Tube Effective top tube is the distance from the center of the head tube to the center of the seat tube/seat post, measured parallel to the ground.
    5. Seat Tube Center to Top Seat Tube length is the measurement of the seat tube, from the center of the cranks to the top of the seat tube.
    6. Head Tube Length Head Tube Length is measured from the bottom to the top of the head tube.
    7. Head Tube Angle Head Tube Angle is the acute angle between the head tube and the ground (measured towards the rear of the bike)
    8. Seat Tube Angle Seat Tube Angle is the acute angle between the seat tube and the ground (measured towards the rear of the bike).
    9. Bottom Bracket Height Bottom Bracket Height is a measurement taken vertically from the ground up to the center of the cranks.
    10. Wheelbase Wheelbase is the measurement from the center of the front axle to the center of the rear axle.
    11. Chainstay Length Chainstay Length is the measurement from the center of the cranks to the center of the rear axle.
    12. Fork Offset Fork Offset, or rake, is the distance from the front axle to a line drawn parallel to the center of the head tube or steering axis.
