Size chart
| XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Height Range | 5'0" - 5'5" | 5'4" - 5'9" | 5'7" - 6'1" | 5'11" - 6'4" | 6'3" - 6'8" |
| Reach | 36.8 | 37.7 | 38.5 | 39.4 | 40.2 |
| Stack | 51.8 | 54.9 | 57.9 | 61.0 | 64.0 |
| Effective Top Tube | 52.5 | 54.4 | 56.1 | 57.9 | 59.6 |
| Seat Tube Center-Top | 41.0 | 45.8 | 50.5 | 55.3 | 60.0 |
| Standover Height | 70.3 | 74.4 | 78.4 | 82.5 | 86.3 |
| Head Tube Length | 8.9 | 11.8 | 14.9 | 18.2 | 21.4 |
| Head Tube Angle (degrees) | 70 | 71 | 71 | 71 | 71 |
| Seat Tube Angle (degrees) | 73.1 | 73.1 | 73.1 | 73.1 | 73.1 |
| Bottom Bracket Height | 7.5 | 7.5 | 7.5 | 7.5 | 7.5 |
| Wheelbase | 101.1 | 102.2 | 104.0 | 106.0 | 107.8 |
| Chainstay | 43.0 | 43.0 | 43.0 | 43.0 | 43.0 |
| Fork Offset | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 |
Sizing notes
Measurements are stated in centimeters unless otherwise indicated.
