Co-op Cycles REV CTY Step-Through Kids' Bike

$319.19 Compared to $399.00 *
Reduced Price. You save 20%
*Intermediate markdowns may have been taken.
Members save 20% on all Co-op Cycles bikes through Aug. 14.
Color:Berry Blue
Size: 24 IN
Quantity
Choose a shipping method
To buy, sign in as an REI Co-op Member or join now.
Members get an estimated 10% back on this item.

Members, get an estimated 10% back on this item as a part of your annual .

The Co-op Cycles REV CTY step-through bike gives young riders an easy-to-straddle stand-over height, to help build confidence and skills for riding— from street to trail.

  • Features

    • Aluminum frame is lightweight and durable
    • Shimano drivetrain provides 21 versatile gearing options for hills, flats and rolling terrain
    • Linear pull rim brakes provide responsive braking power
    • All-terrain tires are mounted on sturdy rims for excellent performance on and off the road
    • Please note: the small frame may not fit standard size bottle cages and water bottles; side entry cages are recommended (not included)
    • Bicycle weight limit is 120 lbs. total, including rider + all gear carried on the bike and on the rider's body
    • Specs and images are subject to change

    Imported.

    Free Adjustment Period:
    New bikes go through a normal break-in period, after which they should be readjusted. All bicycles sold at REI include free adjustments for one year after purchase date—as many times as you need. Included: derailleur and brake adjustments, lateral wheel truing, hub and headset bearing adjustments, tire inflation and chain lubrication. Not included: replacement or installation of new components or accessories, any other services. Call your local REI Co-op Bike Shop for more information.
    View the Co-op Cycles Rev Product Line View all Co-op Cycles Kids' Cruiser Bikes
  • Technical Specs

    Best Use

    Recreational Cycling

    Bike Frame Material

    Aluminum

    Frame

    6061 aluminum

    Step-Through

    Yes

    Bike Suspension

    No Suspension

    Fork

    6061 aluminum

    Crankset

    Alloy, 42/34/24

    Bottom Bracket

    Cartridge

    Shifters

    Shimano Tourney

    Front Derailleur

    Shimano Tourney

    Rear Derailleur

    Shimano Tourney

    Rear Cogs

    Shimano Tourney, 14-34, 7-speed

    Number of Gears

    21 gear(s)

    Brake Type

    Rim Brake

    Brakes

    Logan linear pull

    Rims

    Aluminum

    Front Hub

    Joytech, with nutted axle

    Rear Hub

    Joytech, with nutted axle

    Wheel Size

    24 inches

    Tires

    Kenda Cosmos, 24" x 1.5"

    Tire Width

    1.5 inches

    Handlebar Shape

    Riser Bar

    Handlebar

    Steel riser

    Stem

    Alloy

    Seat Post

    Alloy

    Saddle

    Co-op Cycles

    Pedals

    Wellgo composite platform

    Headset

    Semi cartridge

    Chain

    KMC Z51

    Bike Weight

    Bike weight is based on median size, as sold, or the average of two median sizes.

    Gender

    Kids'

  • Size Chart

    24 IN
    Reach 366.3
    Stack 439.4
    Effective Top Tube 500.58
    Seat Tube Center-Top 320
    Standover Height 579.2
    Head Tube Angle (degrees) 71
    Seat Tube Angle (degrees) 73
    Wheelbase 943.65
    Chainstay 390
    Fork Offset 45

    Sizing Notes

    Measurements are stated in millimeters unless otherwise indicated.

    How we measure bikes

    1. Standover Height Standover Height is a measurement from the ground to the top of the top tube, measured at the midpoint of the top tube.
    2. Reach Reach is the horizontal distance from the center of the cranks to the center of the head tube, measured at head tube level.
    3. Stack Stack is the vertical distance from the center of the cranks to the center of the head tube, measured to the top of the head tube.
    4. Effective Top Tube Effective top tube is the distance from the center of the head tube to the center of the seat tube/seat post, measured parallel to the ground.
    5. Seat Tube Center to Top Seat Tube length is the measurement of the seat tube, from the center of the cranks to the top of the seat tube.
    6. Head Tube Length Head Tube Length is measured from the bottom to the top of the head tube.
    7. Head Tube Angle Head Tube Angle is the acute angle between the head tube and the ground (measured towards the rear of the bike)
    8. Seat Tube Angle Seat Tube Angle is the acute angle between the seat tube and the ground (measured towards the rear of the bike).
    9. Bottom Bracket Height Bottom Bracket Height is a measurement taken vertically from the ground up to the center of the cranks.
    10. Wheelbase Wheelbase is the measurement from the center of the front axle to the center of the rear axle.
    11. Chainstay Length Chainstay Length is the measurement from the center of the cranks to the center of the rear axle.
    12. Fork Offset Fork Offset, or rake, is the distance from the front axle to a line drawn parallel to the center of the head tube or steering axis.
