Cannondale Trail 26 Kids' Mountain Bike

Item #190081
Product Image of color Purple loading
Purple
$510.00
Color: Purple
Size: 26 IN
Quantity
Choose a shipping method

Members get an estimated 10% back on this item as a part of your annual .

To buy,  sign in as an REI Co-op Member or join now.
Join the co-op today to get access to a lifetime of benefits.

Start 'em off right. With its lightweight, kid-size alloy frame, reliable disc brakes and bump-absorbing suspension fork, the kids' Cannondale Trail 26 mountain bike is ready for off-road adventure.

  • Features

    • Lightweight SmartForm C3 Alloy frame and Suntour suspension fork combine to provide a comfortable, bump-absorbing ride
    • 8-speed Tourney derailleur and trigger shifters offer easy, intuitive gear changes
    • Tektro cable-actuated disc brakes provide reliable stopping power
    • StraightShot hidden cable routing makes for clean lines and easy maintenance
    • Rack and fender mounts add versatility for off-trail use (racks and fenders not included)
    • Specs and images are subject to change

    Imported.

    This bike comes with Coast to Coast Support, which includes:
    • 1 year of free adjustments (see more below)
    • In-store bike assembly
    • Pickup in store or curbside
    • Bike experts available at 170+ bike shops
    REI Co-op Members get more:
    • Free flat tire repairs (labor only; parts not included)
    • 20% off shop services
    More about our free adjustments:
    New bikes go through a normal break-in period, after which they should be readjusted. All bicycles sold at REI include free adjustments for one year after purchase date—as many times as you need. Included: derailleur and brake adjustments, lateral wheel truing, hub and headset bearing adjustments, tire inflation and chain lubrication. Not included: replacement or installation of new components or accessories, any other services. Call your local REI Co-op Bike Shop for more information.

    View the Cannondale Trail Product LineView all Cannondale Kids' Mountain Bikes

  • Technical Specs

    Best Use

    Mountain Biking

    Mountain Bike Style

    Trail

    Frame

    SmartForm C3 alloy

    Bike Suspension

    Front Suspension

    Fork

    Suntour M3030, 63 mm, coil with preload adjuster

    Fork Travel

    63 millimeters

    Crankset

    Prowheel, Pro-V30, 152 mm length, 30T

    Bottom Bracket

    Cartridge, square taper

    Shifters

    8-speed

    Rear Derailleur

    microSHIFT M26L

    Rear Cogs

    11-34T, 8-speed

    Number of Gears

    8 gear(s)

    Brake Type

    Mechanical Disc Brake

    Brakes

    Tektro Mechanical Disc, 160/160 mm rotors

    Brake Levers

    Promax BL81

    Rims

    Cannondale Disc, double wall with eyelet, 32 h

    Wheel Size

    26 inches

    Tires

    Kenda Small Block 8, 26 x 1.95 in.

    Tire Width

    1.95 inches

    Handlebar Shape

    Riser Bar

    Handlebar

    6061 alloy, 25 mm rise, 10 deg. sweep, 30 mm rise, 580 mm width

    Stem

    Alloy Ahead, 31.8 mm

    Seat Post

    Alloy, 25.4 mm

    Saddle

    Cannondale Ergo

    Pedals

    Wellgo composite platform

    Headset

    Semi-Integrated, 1-1/8 in.

    Chain

    KMC X8, 8-speed

    Weight

    Unavailable

    Gender

    Kids'

  • Size Chart

    26 IN
    Height Range4'8" - 5'0"
    Reach35.3
    Stack56.4
    Effective Top Tube53.6
    Seat Tube Center-Top34
    Standover Height63.5
    Head Tube Length9.5
    Head Tube Angle (degrees)68
    Seat Tube Angle (degrees)72
    Bottom Bracket Height26
    Wheelbase102.4
    Chainstay43
    Fork Offset4

    Sizing Notes

    Measurements are stated in centimeters unless otherwise noted.

    How we measure bikes

    1. Standover Height Standover Height is a measurement from the ground to the top of the top tube, measured at the midpoint of the top tube.
    2. Reach Reach is the horizontal distance from the center of the cranks to the center of the head tube, measured at head tube level.
    3. Stack Stack is the vertical distance from the center of the cranks to the center of the head tube, measured to the top of the head tube.
    4. Effective Top Tube Effective top tube is the distance from the center of the head tube to the center of the seat tube/seat post, measured parallel to the ground.
    5. Seat Tube Center to Top Seat Tube length is the measurement of the seat tube, from the center of the cranks to the top of the seat tube.
    6. Head Tube Length Head Tube Length is measured from the bottom to the top of the head tube.
    7. Head Tube Angle Head Tube Angle is the acute angle between the head tube and the ground (measured towards the rear of the bike)
    8. Seat Tube Angle Seat Tube Angle is the acute angle between the seat tube and the ground (measured towards the rear of the bike).
    9. Bottom Bracket Height Bottom Bracket Height is a measurement taken vertically from the ground up to the center of the cranks.
    10. Wheelbase Wheelbase is the measurement from the center of the front axle to the center of the rear axle.
    11. Chainstay Length Chainstay Length is the measurement from the center of the cranks to the center of the rear axle.
    12. Fork Offset Fork Offset, or rake, is the distance from the front axle to a line drawn parallel to the center of the head tube or steering axis.
