Cannondale Trail 6 Mountain Bike
$519.93Compared to $650.00* Save 20%
Hit hard turns and hefty hills on the Cannondale Trail 6 hardtail mountain bike. It's built to handle the mountains with a light alloy frame, Shimano components and shock-absorbing front suspension.
Key Details
Wheel Size
XS: 27.5 inches
M: 29 inches
XL: 29 inches
Fork Travel
100 millimeters
Number of Gears
16 gear(s)
- Durable SmartForm C3 alloy frame delivers an exceptionally lightweight, efficient and smooth ride
- SR Suntour XCM fork offers 100 mm of travel with smooth suspension
- Shimano M315 Rapidfire Plus 2 x 8-speed shifting handles steep climbs while delivering smooth, efficient shifting
- Reliable Shimano hydraulic disc brakes provide great stopping power and control
- SAVE micro-suspension offers a smoother, more controlled ride with strategically engineered flex zones built into the frame's rear triangle
- Slack 68° head angle creates exceptionally stable handling to charge the descents with confidence
- WTB Ranger Comp wheels rip around every turn with steadfast grip
- StraightShot internal cable routing for shifting and dropper post cables in the down tube makes for clean lines and easy maintenance; rear brake line runs outside the frame
- Compatible with 31.6 mm dropper posts (not included)
- NOTE: Specs and images are subject to change based on component availability
Imported.
This bike comes with Coast to Coast Support, which includes:
New bikes go through a normal break-in period, after which they should be readjusted. All bicycles sold at REI include free adjustments for one year after purchase date—as many times as you need. Included: derailleur and brake adjustments, lateral wheel truing, hub and headset bearing adjustments, tire inflation and chain lubrication. Not included: replacement or installation of new components or accessories, any other services. Call your local REI Co-op Bike Shop for more information.
View the Cannondale Trail Product LineView all Cannondale Hardtail Mountain Bikes- 1 year of free adjustments (see more below)
- In-store bike assembly
- Pickup in store or curbside
- Bike experts available at 170+ bike shops
- 20% off shop services
- Free tubes with purchase of flat tire repair (Co-op Cycles brand tubes only; tube must be installed at time of purchase)
New bikes go through a normal break-in period, after which they should be readjusted. All bicycles sold at REI include free adjustments for one year after purchase date—as many times as you need. Included: derailleur and brake adjustments, lateral wheel truing, hub and headset bearing adjustments, tire inflation and chain lubrication. Not included: replacement or installation of new components or accessories, any other services. Call your local REI Co-op Bike Shop for more information.
| Best Use | Mountain Biking |
|---|---|
| Mountain Bike Style | Trail |
| Frame | SmartForm C3 alloy, 1 1/8 in. head tube, dropper post compatible |
| Bike Suspension | Front Suspension |
| Fork | SR Suntour XCT, 100mm, coil, 42mm offset (27.5 in.) 46mm offset (29 in.) |
| Fork Travel | 100 millimeters |
| Crankset | Prowheel, 36/22T |
| Bottom Bracket | Cartridge, square taper |
| Shifters | Shimano M315 Rapidfire Plus, 2x8-speed |
| Front Derailleur | Shimano Altus, 34.9 clamp |
| Rear Derailleur | Shimano Acera |
| Rear Cogs | 11-34T, 8-speed |
| Number of Gears | 16 gear(s) |
| Brake Type | Hydraulic Disc Brake |
| Brakes | Tektro M275 hydraulic disc, 160/160mm rotors |
| Brake Levers | Shimano MT200 hydraulic disc |
| Rims | WTB SX19, 32 h |
| Front Hub | Shimano HBTX 505 |
| Rear Hub | Shimano FHTX505 |
| Wheel Size | XS: 27.5 inches M: 29 inches XL: 29 inches |
| Tires | WTB Ranger Comp |
| Tire Width | 2.25 inches |
| Handlebar Shape | Riser Bar |
| Handlebar | 6061 alloy, 25 mm rise, 8 deg. sweep, 6 deg. rise, 720 mm |
| Stem | 6061 alloy, 31.8, 7 degree |
| Seat Post | C3, 6061 alloy, 31.6 x 350/400 mm |
| Saddle | Cannondale Stage 3 |
| Pedals | Cannondale Platform |
| Headset | 1-1/8 in. |
| Chain | KMC X8, 8-speed |
| Weight | 32 lbs. 12.8 oz. |
| Bike Weight | Bike weight is based on median size, as sold, or the average of two median sizes. |
| Gender | Unisex |
Cannondale Bikes (183884, 184495, 184494, 184493, 184497)
| XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Height Range | 4'6" - 5'2" | 5'1" - 5'4" | 5'4" - 5'8" | 5'7" - 6'0" | 6'0" - 6'3" |
| Reach | 36.5 | 40.2 | 42.5 | 44.7 | 47.0 |
| Stack | 60.7 | 61.6 | 62.4 | 63.3 | 64.3 |
| Effective Top Tube | 54.5 | 58.5 | 61.0 | 63.5 | 66.0 |
| Seat Tube Center-Top | 34.5 | 40.0 | 44.0 | 48.0 | 52.0 |
| Standover Height | 71.0 | 74.6 | 79.5 | 82.0 | 85.0 |
| Head Tube Length | 9.5 | 10.5 | 11.5 | 12.5 | 13.5 |
| Head Tube Angle (degrees) | 68.0 | 68.0 | 68.5 | 68.5 | 68.5 |
| Seat Tube Angle (degrees) | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
| Bottom Bracket Height | 30.4 | 30.4 | 30.8 | 30.8 | 30.8 |
| Wheelbase | 106.7 | 110.8 | 114.0 | 116.6 | 119.2 |
| Chainstay | 44.0 | 44.0 | 44.5 | 44.5 | 44.5 |
| Fork Offset | 4.2 | 4.2 | 5.1 | 5.1 | 5.1 |
Sizing Notes
Measurements are stated in centimeters unless otherwise indicated.
How we measure bikes
- Standover Height Standover Height is a measurement from the ground to the top of the top tube, measured at the midpoint of the top tube.
- Reach Reach is the horizontal distance from the center of the cranks to the center of the head tube, measured at head tube level.
- Stack Stack is the vertical distance from the center of the cranks to the center of the head tube, measured to the top of the head tube.
- Effective Top Tube Effective top tube is the distance from the center of the head tube to the center of the seat tube/seat post, measured parallel to the ground.
- Seat Tube Center to Top Seat Tube length is the measurement of the seat tube, from the center of the cranks to the top of the seat tube.
- Head Tube Length Head Tube Length is measured from the bottom to the top of the head tube.
- Head Tube Angle Head Tube Angle is the acute angle between the head tube and the ground (measured towards the rear of the bike)
- Seat Tube Angle Seat Tube Angle is the acute angle between the seat tube and the ground (measured towards the rear of the bike).
- Bottom Bracket Height Bottom Bracket Height is a measurement taken vertically from the ground up to the center of the cranks.
- Wheelbase Wheelbase is the measurement from the center of the front axle to the center of the rear axle.
- Chainstay Length Chainstay Length is the measurement from the center of the cranks to the center of the rear axle.
- Fork Offset Fork Offset, or rake, is the distance from the front axle to a line drawn parallel to the center of the head tube or steering axis.
