The nitty gritty
Size chart
| S | M | L | XL | |
| Reach | 40.1 | 42.1 | 44.1 | 45.1 |
| Stack | 60.7 | 61.9 | 63.1 | 64.2 |
| Effective Top Tube | 58.7 | 61.0 | 63.4 | 64.7 |
| Seat Tube Center-Top | 39.0 | 44.0 | 49.0 | 54.0 |
| Standover Height | 44.3 | 47.4 | 50.8 | 54.2 |
| Head Tube Length | 9.7 | 11.0 | 12.2 | 13.4 |
| Head Tube Angle (degrees) | 69.1 | 69.1 | 69.1 | 69.1 |
| Seat Tube Angle (degrees) | 73.0 | 73.0 | 73.0 | 73.0 |
| Bottom Bracket Height | 32.4 | 32.4 | 32.4 | 32.4 |
| Wheelbase | 112.7 | 115.2 | 117.6 | 119.0 |
| Chainstay | 45.6 | 45.6 | 45.6 | 45.6 |
| Fork Offset | 6.0 | 6.0 | 6.0 | 6.0 |
Sizing notes
Measurements are stated in centimeters unless otherwise indicated.
