The nitty gritty
Size chart
| 44 CM | 48 CM | 51 CM | 54 CM | |
|---|---|---|---|---|
| Height Range | 4'10" - 5'01" | 5'1"- 5'3" | 5'3"- 5'5" | 5'5"- 5'8" |
| Reach | 36.5 | 37.1 | 37.1 | 38.3 |
| Stack | 51.0 | 53.0 | 55.0 | 57.0 |
| Effective Top Tube | 50.5 | 51.7 | 53.1 | 54.7 |
| Seat Tube Center-Top | 40.0 | 42.2 | 44.3 | 48.0 |
| Standover Height | 68.0 | 70.1 | 72.2 | 75.5 |
| Head Tube Length | 10.4 | 12.3 | 14.3 | 15.9 |
| Head Tube Angle (degrees) | 70.2° | 70.8° | 71.0° | 71.9° |
| Seat Tube Angle (degrees) | 74.7° | 74.6° | 74.3° | 73.9° |
| Bottom Bracket Height | 27.0 | 27.0 | 27.0 | 27.2 |
| Wheelbase | 99.2 | 99.9 | 101.0 | 100.4 |
| Chainstay | 41.3 | 41.3 | 41.3 | 41.3 |
| Fork Offset | 6.0 | 6.0 | 6.0 | 5.0 |
Sizing notes
Measurements are stated in centimeters unless otherwise indicated.
