The nitty gritty
Size chart
| S | M | L | XL | |
| Height Range | 5'4" to 5'7" | 5'7" to 5'10" | 5'10" to 6'1" | 6'1" to 6'4" |
| Reach | 388 | 396 | 404 | 412 |
| Stack | 554 | 578 | 602 | 626 |
| Effective Top Tube | 557 | 573 | 588 | 603 |
| Seat Tube Center-Top | 400 | 450 | 500 | 550 |
| Standover Height | 690 | 731 | 772 | 812 |
| Head Tube Length | 134 | 160 | 185 | 211 |
| Head Tube Angle (degrees) | 70 | 70 | 70 | 70 |
| Seat Tube Angle (degrees) | 73 | 73 | 73 | 73 |
| Bottom Bracket Height | 277 | 277 | 277 | 277 |
| Wheelbase | 1053 | 1070 | 1086 | 1103 |
| Chainstay | 435 | 435 | 435 | 435 |
| Fork Offset | 55 | 55 | 55 | 55 |
Sizing notes
Bike measurements are stated in millimeters.
