Salsa Confluence CUES 11 Electric Bike
Squeeze more adventure into each day with this Salsa e-bike. It empowers riders to chase gravel with low-torque assist. Plus it has mounts for on-bike cargo for any mission.
Key Details
- 6061-T6 aluminum alloy frame
- Carbon fork offers a compliant ride and keeps weight down
- Geometry is designed for comfort and stability
- Suspension-corrected for 40 mm gravel suspension forks (not included)
- MAHLE X30 class 1 hub-drive system with 45 Nm max torque
- 250Wh internal battery
- Multiple mounting points for on-bike storage, including both rack and fender mounts (racks and fenders not included)
- HMI compact remote top tube controller
- Shimano CUES 1 x 11-speed drivetrain with hydraulic brakes
- 42T chainring with 11–50T cassette
- Salsa handlebar and stem
- Spec'd with tubeless-ready WTB i25 wheels and Teravail Washburn 700c x 50 mm with Durable casing tires
- Accommodates up to 700c x 50 mm tires without fenders; 700c x 42mm maximum tire clearance with fenders
- Pedals not included
- NOTE: Specs and images are subject to change based on component availability
Imported.
- 1 year of free adjustments (see more below)
- In-store bike assembly
- Pickup in store or curbside
- Bike experts available at 170+ bike shops
- An additional year of free adjustments on e-bikes
- 20% off shop services
- Free tubes with purchase of flat tire repair (Co-op Cycles brand tubes only; tube must be installed at time of purchase)
New bikes go through a normal break-in period, after which they should be readjusted. All electric bicycles sold at REI include free adjustments for the defined period (one year after purchase date for non-members, or two years for REI Co-op Members)—as many times as you need. Included: derailleur and brake adjustments, lateral wheel truing, hub and headset bearing adjustments, tire inflation, chain lubrication and e-bike firmware updates. Not included: replacement or installation of new components or accessories, any other services. Call your local REI Co-op Bike Shop for more information.
UL2849 certified
| Best Use | Gravel Cycling |
|---|---|
| E-Bike Classification | Class 1: pedal assist up to 20 mph |
| Motor | MAHLE X30 |
| Motor Type | Geared Hub |
| Motor Torque (Nm) | 45 Newton meters |
| Battery Type | Lithium Ion |
| Battery Capacity (Wh) | 250 watt hours |
| Battery Removable | No |
| Charge Time (hrs) | 3.5 hours |
| Frame | Aluminum |
| Step-Through | No |
| Bike Suspension | No Suspension |
| Fork | Carbon |
| Crankset | Shimano CUES U6030, 42T |
| Shifters | Shimano CUES U6030 |
| Rear Derailleur | Shimano CUES U6000 |
| Rear Cogs | Shimano CUES U6000, 11–50T, 11-speed |
| Number of Gears | 11 gear(s) |
| Brake Type | Hydraulic Disc Brake |
| Brakes | Shimano CUES U6030 |
| Brake Levers | Shimano CUES U6030 |
| Rims | WTB KOM Team i25 |
| Front Hub | WTB |
| Rear Hub | MAHLE X30 |
| Wheel Size | 700c |
| Tires | Teravail Washburn |
| Tire Width | 50 millimeters |
| Handlebar Shape | Drop Bar |
| Handlebar | Salsa Cowbell |
| Stem | Salsa Guide |
| Seat Post | Promax 12 mm setback |
| Saddle | WTB Volt |
| Pedals | Not included |
| Headset | FSA |
| Chain | Shimano LG500 |
| Weight | Unavailable |
| Gender | Unisex |
| 51 CM | 53 CM | 55 CM | 57 CM | 60 CM | |
|---|---|---|---|---|---|
| Height Range | 4'10" - 5'2" | 5'1" - 5'6" | 5'4" - 5'9" | 5'7" - 6'0" | 5'11" - 6'4" |
| Reach | 372.9 | 369.1 | 372.8 | 384.2 | 405.7 |
| Stack | 537.8 | 561.1 | 579.7 | 607.6 | 635.5 |
| Effective Top Tube | 517 | 530 | 550 | 570 | 600 |
| Seat Tube Center-Top | 380 | 410 | 450 | 490 | 520 |
| Standover Height | 667 | 698 | 733 | 769 | 797 |
| Head Tube Length | 105 | 130 | 150 | 180 | 210 |
| Head Tube Angle (degrees) | 68.5 | 68.5 | 68.5 | 68.5 | 68.5 |
| Seat Tube Angle (degrees) | 75 | 74 | 73 | 73 | 73 |
| Wheelbase | 1046.4 | 1051.8 | 1062.8 | 1085.2 | 1117.7 |
| Chainstay | 440 | 440 | 440 | 440 | 440 |
| Fork Offset | 51 | 51 | 51 | 51 | 51 |
Sizing Notes
Measurements are stated in millimeters unless otherwise indicated.
How we measure bikes
- Standover Height Standover Height is a measurement from the ground to the top of the top tube, measured at the midpoint of the top tube.
- Reach Reach is the horizontal distance from the center of the cranks to the center of the head tube, measured at head tube level.
- Stack Stack is the vertical distance from the center of the cranks to the center of the head tube, measured to the top of the head tube.
- Effective Top Tube Effective top tube is the distance from the center of the head tube to the center of the seat tube/seat post, measured parallel to the ground.
- Seat Tube Center to Top Seat Tube length is the measurement of the seat tube, from the center of the cranks to the top of the seat tube.
- Head Tube Length Head Tube Length is measured from the bottom to the top of the head tube.
- Head Tube Angle Head Tube Angle is the acute angle between the head tube and the ground (measured towards the rear of the bike)
- Seat Tube Angle Seat Tube Angle is the acute angle between the seat tube and the ground (measured towards the rear of the bike).
- Bottom Bracket Height Bottom Bracket Height is a measurement taken vertically from the ground up to the center of the cranks.
- Wheelbase Wheelbase is the measurement from the center of the front axle to the center of the rear axle.
- Chainstay Length Chainstay Length is the measurement from the center of the cranks to the center of the rear axle.
- Fork Offset Fork Offset, or rake, is the distance from the front axle to a line drawn parallel to the center of the head tube or steering axis.
