Cane Creek Hellbender 70 Headset

$100.00to $120.00
Color: Black
please select a Size
$120.00
$117.00
$100.00
Quantity
Select size for delivery dates
Shipping restrictions may apply.

With top-tier design, sealing elements and Hellbender bearings, the Cane Creek Hellbender 70 headset keeps you riding smoothly through rain, mud, grit, or whatever the road and trail throw at you.

Features

  • Hellbender stainless-steel bearings with advanced sealing elements are built to live in the most extreme conditions
  • 6061 T-6 aluminum cups are internally contoured and relieved to minimize weight and maximize strength
  • Alloy Dual-Seal crown race provides excellent seal efficiency with low friction
  • Interlok® spacer compatible (spacers not included)
  • Low-friction upper bearing seal completely seals cup from contaminants and is fully captured by the top cover with no loose parts
  • Bright-dip black anodized finish
  • External cups press into head tube
  • Integrated bearings fit directly into compatible head tubes without the need for a bearing press
  • Zero stack uppers press into head tube with very little stack height
  • Backed by the manufacturer's 2-year warranty

Imported.

How to select your size:

Sizes are formatted as
S.H.I.S. Upper / S.H.I.S Stem Clamp Diameter / S.H.I.S. Lower / Crown Race
(S.H.I.S. stands for Standardized Headset Identification System)

S.H.I.S. upper and lower cups:
  • EC indicates External Cup (stack height: 12 mm bottom)
  • ZS indicates ZeroStack (stack height: 8 mm top/4 mm bottom)
  • IS indicates Integrated (stack height: 9 mm top/1 mm bottom)

Bearing sizes:
  • ZS44 takes a 41 mm bearing
  • EC44 takes a 52 mm bearing
  • ZS56 takes a 52 mm bearing
  • IS41 takes a 41 mm bearing
  • IS42 takes a 42 mm bearing
  • IS52 takes a 52 mm bearing
View all Cane Creek Bike Headsets

Technical Specs

Best Use

Cycling

Headset Type

Complete Headset

Headset Design

Threadless

Upper Stack Height

ZS44/28.6/ZS56/40: 8 millimeters

ZS44/28.6/EC44/40: 8 millimeters

IS41/28.6/IS52/40: 9 millimeters

IS42/28.6/IS52/40: 9 millimeters

Lower Stack Height

ZS44/28.6/ZS56/40: 4 millimeters

ZS44/28.6/EC44/40: 12 millimeters

IS41/28.6/IS52/40: 1 millimeters

IS42/28.6/IS52/40: 1 millimeters

Weight

Unavailable

Material(s)

6061 T-6 aluminum/stainless steel
