Cannondale  Trail 8 Mountain Bike

$535.00
This item is not eligible for Member Coupons.
Color: Grey
please select a Size
Quantity
Select size for delivery dates
Shipping restrictions apply.
Oversize shipping may apply.

Members get an estimated 10% back on this item as a part of your annual .

To buy,  sign in as an REI Co-op Member or join now.
Join the co-op today to get access to a lifetime of benefits.

Built to ignite a passion for the trail and raise your game, the hardtail Cannondale Trail 8 bike is ready to take on the mountains with its progressive geometry and seriously dirt-ready components.

Features

  • With 27.5 in. wheels on smaller sizes and 29 in. wheels on larger sizes, the Trail delivers the best blend of fit, fast and fun for every rider
  • Durable SmartForm C3 alloy frame is light and lively, stiff and snappy
  • SAVE micro-suspension delivers a smoother, more controlled ride, thanks to strategically engineered flex zones built into the frame's rear triangle
  • SR Suntour M3030 suspension fork with 75 mm travel smooths out bumps, absorbs shock and improves control
  • 2 x 7-speed drivetrain offers the wide range of gears you need to take on the trails
  • Tektro mechanical disc brakes provide reliable stopping power for all conditions
  • A slack 68° head angle creates exceptionally stable handling so you can charge the descents with confidence
  • Shift and dropper cables route cleanly through the StraightShot window in down tube for an integrated look and easy maintenance; rear brake line is secured outside the frame
  • Dropper post compatible—accepts 31.6 mm dropper posts (not included) for more confident descending
  • Specs and images are subject to change

Imported.

This bike comes with Coast to Coast Support, which includes:
  • 1 year of free adjustments (see more below)
  • In-store bike assembly
  • Pickup in store or curbside
  • Bike experts available at 170+ bike shops
REI Co-op Members get more:
  • 20% off shop services
  • Free tubes with purchase of flat tire repair (Co-op Cycles brand tubes only; tube must be installed at time of purchase)
More about our free adjustments:
New bikes go through a normal break-in period, after which they should be readjusted. All bicycles sold at REI include free adjustments for one year after purchase date—as many times as you need. Included: derailleur and brake adjustments, lateral wheel truing, hub and headset bearing adjustments, tire inflation and chain lubrication. Not included: replacement or installation of new components or accessories, any other services. Call your local REI Co-op Bike Shop for more information.

View the Cannondale Trail Product LineView all Cannondale Hardtail Mountain Bikes

Technical Specs

Item #184495
Best Use

Mountain Biking

Mountain Bike Style

Trail

Frame

SmartForm C3 Alloy, post mount disc

Bike Suspension

Front Suspension

Fork

SR Suntour M3030, coil, 42 mm offset (27.5 in.) 46 mm offset (29 in.)

Fork Travel

75 millimeters

Crankset

Prowheel, 36/22T

Bottom Bracket

Cartridge, BSA-73, square taper

Shifters

microSHIFT Thumb-Tap, 7-speed

Front Derailleur

Shimano Altus, 34.9 mm clamp

Rear Derailleur

Shimano Tourney

Rear Cogs

11-34T, 7-speed

Number of Gears

14 gear(s)

Brake Type

Mechanical Disc Brake

Brakes

Tektro cable-actuated disc, 160/160 mm rotors

Brake Levers

Tektro

Rims

WTB SX19, 32H

Front Hub

Formula quick-release

Rear Hub

Formula quick-release

Wheel Size

XS: 27.5 inches

S: 27.5 inches

M: 29 inches

L: 29 inches

XL: 29 inches

Tires

XS: WTB Ranger Comp, 27.5 x 2.25 in., DNA Compound

S: WTB Ranger Comp, 27.5 x 2.25 in., DNA Compound

M: WTB Ranger Comp, 29 x 2.25 in., DNA Compound

L: WTB Ranger Comp, 29 x 2.25 in., DNA Compound

XL: WTB Ranger Comp, 29 x 2.25 in., DNA Compound

Tire Width

2.25 inches

Handlebar Shape

Riser Bar

Handlebar

6061 alloy riser, 31.8 mm, 25 mm rise, 700 mm

Stem

6061 alloy, 31.8 mm, 8 deg.

Seat Post

Cannondale 3, 6061 alloy, 31.6 x 350/400 mm

Saddle

Cannondale Stage 3

Pedals

Cannondale Platform

Headset

1-1/8 in.

Chain

KMC Z7, 7-speed

Weight

32 lbs. 14.4 oz.

Bike Weight

Bike weight is based on median size, as sold, or the average of two median sizes.

Gender

Unisex

Size Chart

XSSMLXL
Height Range4'6" - 5'2"5'1" - 5'4"5'4" - 5'8"5'7" - 6'0"6'0" - 6'3"
Reach36.540.242.544.747.0
Stack60.761.662.463.364.3
Effective Top Tube54.558.561.063.566.0
Seat Tube Center-Top34.540.044.048.052.0
Standover Height71.074.679.582.085.0
Head Tube Length9.510.511.512.513.5
Head Tube Angle (degrees)68.068.068.568.568.5
Seat Tube Angle (degrees)73.573.573.573.573.5
Bottom Bracket Height30.430.430.830.830.8
Wheelbase106.7110.8114.0116.6119.2
Chainstay44.044.044.544.544.5
Fork Offset4.24.25.15.15.1

Sizing Notes

Measurements are stated in centimeters unless otherwise indicated.

How we measure bikes

  1. Standover Height Standover Height is a measurement from the ground to the top of the top tube, measured at the midpoint of the top tube.
  2. Reach Reach is the horizontal distance from the center of the cranks to the center of the head tube, measured at head tube level.
  3. Stack Stack is the vertical distance from the center of the cranks to the center of the head tube, measured to the top of the head tube.
  4. Effective Top Tube Effective top tube is the distance from the center of the head tube to the center of the seat tube/seat post, measured parallel to the ground.
  5. Seat Tube Center to Top Seat Tube length is the measurement of the seat tube, from the center of the cranks to the top of the seat tube.
  6. Head Tube Length Head Tube Length is measured from the bottom to the top of the head tube.
  7. Head Tube Angle Head Tube Angle is the acute angle between the head tube and the ground (measured towards the rear of the bike)
  8. Seat Tube Angle Seat Tube Angle is the acute angle between the seat tube and the ground (measured towards the rear of the bike).
  9. Bottom Bracket Height Bottom Bracket Height is a measurement taken vertically from the ground up to the center of the cranks.
  10. Wheelbase Wheelbase is the measurement from the center of the front axle to the center of the rear axle.
  11. Chainstay Length Chainstay Length is the measurement from the center of the cranks to the center of the rear axle.
  12. Fork Offset Fork Offset, or rake, is the distance from the front axle to a line drawn parallel to the center of the head tube or steering axis.
