The nitty gritty
Size chart
| XS | S | M | L | XL | |
| Height Range | 150 - 160cm | 160 - 175cm | 173 - 183cm | 180 - 191cm | 188cm and up |
| Reach | 349.7 | 352 | 368.4 | 384.8 | 409.1 |
| Stack | 594 | 615 | 643.1 | 671.1 | 689.7 |
| Effective Top Tube | 520 | 540 | 565 | 590 | 620 |
| Seat Tube Center-Top | 355.6 | 406.4 | 457.2 | 508 | 558.8 |
| Standover Height | 690 | 732 | 778 | 821 | 859 |
| Head Tube Length | 90 | 110 | 140 | 170 | 190 |
| Head Tube Angle (degrees) | 68.5 | 69 | 69 | 69 | 69 |
| Seat Tube Angle (degrees) | 74 | 74 | 73 | 73 | 73 |
| Wheelbase | 1045 - 1061 | 1061 - 1078 | 1077 - 1093 | 1104 - 1120 | 1136 - 1152 |
| Chainstay | 445 - 462 | 445 - 462 | 445 - 462 | 445 - 462 | 445 - 462 |
| Fork Offset | 45 | 45 | 45 | 45 | 45 |
Sizing notes
Measurements are stated in millimeters unless otherwise indicated.
