The nitty gritty
Size chart
| 49.5 CM | 52 cm | 54 cm | 55 cm | 57 cm | 59 cm | |
|---|---|---|---|---|---|---|
| Height Range | 4'10"-5'2" | 5'2"-5'5" | 5'5"-5'8" | 5'7"-5'10" | 5'9"-6'1" | 6'1"+ |
| Reach | 14 | 14.5 | 14.4 | 14.3 | 14.6 | 15.1 |
| Stack | 21.4 | 21.6 | 23.2 | 24 | 24.7 | 25.5 |
| Effective Top Tube | 19.49 | 20.47 | 21.26 | 21.65 | 22.44 | 23.43 |
| Seat Tube Center-Top | 14.96 | 17.72 | 18.5 | 20.08 | 20.87 | 22.05 |
| Standover Height | 26 | 28.1 | 29.2 | 30.6 | 31.3 | 32.3 |
| Head Tube Length | 3.94 | 3.94 | 5.71 | 6.5 | 7.28 | 8.07 |
| Head Tube Angle (degrees) | 70.25 | 71.5 | 71.5 | 71.5 | 71.5 | 71.5 |
| Seat Tube Angle (degrees) | 75.5 | 74.5 | 73.5 | 73 | 72.5 | 72 |
| Wheelbase | 40.1 | 40.3 | 40.7 | 40.9 | 41.5 | 42.2 |
| Chainstay | 17.72 | 17.72 | 17.72 | 17.72 | 17.72 | 17.72 |
| Fork Offset | 1.97 | 1.97 | 1.97 | 1.97 | 1.97 | 1.97 |
Sizing notes
Measurements are stated in inches unless otherwise indicated.
