The nitty gritty
Size chart
| 52 CM | 54 CM | 56 CM | 58 CM | 60 CM | |
| Height Range | 5'4"-5'7" | 5'4"-5'7" | 5'9" - 5'11" | 5'11"-6'1" | 5'11"-6'1" |
| Reach | 371 | 375 | 378 | 388 | 391 |
| Stack | 553 | 566 | 595 | 612 | 631 |
| Effective Top Tube | 530 | 545 | 560 | 575 | 590 |
| Seat Tube Center-Top | 490 | 510 | 530 | 550 | 570 |
| Standover Height | 756 | 778 | 802 | 858 | 843 |
| Head Tube Length | 135 | 150 | 180 | 200 | 220 |
| Head Tube Angle (degrees) | 72.5 | 72.75 | 73 | 73 | 73 |
| Seat Tube Angle (degrees) | 74 | 73.25 | 73 | 73 | 72.5 |
| Bottom Bracket Height | 273.5 | 276 | 276 | 278.5 | 278.5 |
| Wheelbase | 981 | 987 | 997 | 1013 | 1022 |
| Chainstay | 415 | 415 | 415 | 415 | 415 |
| Fork Offset | 47.5 | 47.5 | 47.5 | 47.5 | 47.5 |
Sizing notes
Measurements are stated in millimeters unless otherwise indicated.
