Size chart
| XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Reach | 36.6 | 40.0 | 43.0 | 46.0 | 49.0 |
| Stack | 60 | 60.7 | 61.6 | 62.5 | 63.4 |
| Effective Top Tube | 53.8 | 57.3 | 60.6 | 63.9 | 67.1 |
| Seat Tube Center-Top | 38 | 40 | 44 | 48 | 52 |
| Standover Height | 70 | 72 | 75 | 77 | 78 |
| Head Tube Length | 9.5 | 10.5 | 11.5 | 12.5 | 13.5 |
| Head Tube Angle (degrees) | 66.0° | 66.0° | 66.0° | 66.0° | 66.0° |
| Seat Tube Angle (degrees) | 66.3° | 66.3° | 66.3° | 66.3° | 66.3° |
| Bottom Bracket Height | 33.1 | 33.9 | 33.9 | 33.9 | 33.9 |
| Wheelbase | 110.3 | 114.2 | 117.6 | 121 | 124.4 |
| Chainstay | 43.5 | 43.5 | 43.5 | 43.5 | 43.5 |
| Fork Offset | 4.4 | 5.1 | 5.1 | 5.1 | 5.1 |
Sizing notes
Measurements are stated in centimeters unless otherwise indicated.
